The AP AP305C-WR is part of Extreme’s Universal Wi-Fi platform and provides users the choice of Wi-Fi operating system (IQ Engine or WiNG Operating System).Customers have the ffexibility to select the OS at start-up or at a later stage andthe AP will assume the features/capabilities of the selected OS. When ffrst booted,the AP305C-WR automatically connects to ExtremeCloud IQ to ffnd its persona.The pre-provisioned OS persona is then remotely enabled on the AP305C-WR APand the user can stay in the cloud or select manage the device locally.The AP305C-WR are indoor enterprise APs based on a new system-on-a-chip(SoC) with two built-in dual-band radios providing the best value with Wi-Fi6 high efffciency. The AP305C-WR platforms are the first generation of APs torun multiple Extreme operating systems, providing flexibility and choice of on premiseor cloud deployment, while minimizing total cost of ownership. You have your choice of models with either integrated or external antennas. Advanced radio technology delivers 802.11ax 2×2:2 data rates up to 2.4 Gbps concurrently on both the 2.4 GHz and 5 GHz radios. These 2×2:2 APs continue the Extreme tradition of software-selectable radios (SSRs) capable of dual 5 GHz connectivity for indoor and industrial environments. This enterprise-grade access point is ideal for budget-conscious enterprises who do not want to sacriffce performance.
The AP305C-WR comes in an aesthetic design and can fft in the palm of your hand. Both models are eco-friendly APs partially
made from recycled materials. Also included is an integrated light sensor and integrated power meter to help conserve power
consumption*. The easy install ceiling mount for quick installation and unique way to hide the Ethernet cables for an aesthetically pleasing installation. Despite the exponential growth of users, BYOD devices, IoT, high-bandwidth applications and security threats straining the infrastructure, the AP305C-WR combines performance, security services and insightful ML/AI management capabilities to deliver an enterprise class solution at a value price.
| MKT Product sKU | Description |
|---|---|
| AP 305C-WR | ExtremeCloud lQ: indoor Wi-Fi 6 AP, 2x2 radios with Dual 5GHz and ixiGbE port. integrated light/power sensors and BLEAl/ML green mode, internal antennas, Built-in ceiling mounts. lncludes Connect. Domain: EMEA, Rest of World |
| AP 305CX-WR | ExtremeCloud lQ: indoor Wi-Fi 6 AP, 2x2 radios with Dual 5GHz and ixiGbE port. integrated light/power sensors and BLEAl/ML green mode. External antennas. Built-in ceiling mounts. includes Connect. Domain: EMEA, Rest of World |
| AP305C-1-WR* | ExtremeCloud lQ indoor Wi-Fi 6 AP 2x2 radios with Dual 5GHz and 1xl GbE port. integrated light/power sensors. Al/ML green mode. Internal antennas. Includes Connect. Domain: Rest of World |
Radio Technology
Radio Modes – SSR
Universal Hardware Platform
High Density Environments
WPA3 Support
Fully Functional over 802.3af
Cellular Coexistence Filter (CCF)
Smart Management
