Mellanox cable MFP7E10-N015 Passive Fiber Cable MMF MPO12 APC to MPO12 APC 15m

Manufacturer:     Mellanox

Model number:   MFP7E10-N010

Condition:           New and original

  • {mellanox}

Description

Mellanox cable MFP7E10-N015 Passive Fiber Cable MMF MPO12 APC to MPO12 APC 15m

MFP7E10-N015 Twin-port NDR transceiver has a unique NVIDIA patented design enabling two, multiple-push-on/angled-polished connector 12-fiber (MPO-12/APC) optical connectors per single OSFP form-factor by turning the optical connectors vertically in the twin-port transceiver end. MFP7E10-N015 enables it to host two NDR transceivers inside, each with its own MPO-12/APC optical connector operating independently that can link to another Twin-port transceiver or to a single port 400Gb/s NDR transceiver.

MFP7E10-N015 MPO-12 has a 12-fiber ribbon but only 8-fibers are used – four transmit and four receive fibers for the 4-channels of 100G-PAM4 NDR. The APC design minimizes back reflections and signal interference by diverting back reflected light from the fiber face to be absorbed into the fiber cladding. A positioning key on top of the connector together with the alignment pins define the fiber position numbering scheme to align pin 1 in the optical connector to pin 1 in the transceiver also called “polarity” Transceivers have alignment pins for precise positioning of the cable connector against the optical beams. The fiber cable has alignment holes matching the transceiver’s pins. It is important to note that transceivers have pins. Optical connectors have holes and are used with transceivers. Optical connectors with pins are not compatible with transceivers and are used in trunk cabling to connect two fiber cables together.

The MPO-12/APC optical connector is used in both the NDR single mode and multimode fiber cables. Multimode optics is denoted by a tan-colored pull tab and aqua-colored optical fiber. Green plastic shell on the MPO-12/APC connector denotes Angled Polish Connector and is not compatible with aqua colored shell for Ultra-flat Polished Connectors (UPC) for HDR. MPO-12/APC Showing 4-Transmit and 4-Receive Fibers and Angled Polish Connector End.

MFP7E10-N015 Specifications

Model number 4-channel MPO/APC to 4-channel MPO/APC
MFP7E10-N003 3m
MFP7E10-N005 5m
MFP7E10-N007 7m
MFP7E10-N010 10m
MFP7E10-N015 15m
MFP7E10-N020 20m
MFP7E10-N030 30m
MFP7E10-N050 50m
  • A positioning key on top of the connector together with the alignment pins define the fiber position numbering scheme to align pin 1 in the optical connector to pin 1 in the transceiver also called “polarity”
  • Transceivers have alignment pins for precise positioning of the cable connector against the optical beams. The fiber cable has alignment holes matching the transceiver’s pins.
  • It is important to note that transceivers have pins. Optical connectors have holes and are used with transceivers. Optical connectors with pins are not compatible with transceivers and are used in trunk cabling to connect two fiber cables together.

MFP7E10-N015 The MPO-12/APC optical connector is used in both the NDR single mode and multimode fiber cables. Multimode optics is denoted by a tan-colored pull tab and aqua-colored optical fiber. Green plastic shell on the MPO-12/APC connector denotes Angled Polish Connector and is not compatible with aqua colored shell for Ultra-flat Polished Connectors (UPC) for HDR. MPO-12/APC Showing 4-Transmit and 4-Receive Fibers and Angled Polish Connector End.

NVIDIA Supplied Crossover Type-B Fiber Cables
Linking two transceivers directly together requires aligning the transceiver laser sources with the correct photodetectors in the receive transceiver. Transmit and receive fibers are switched inside the cable enabling twotransceivers to be directly connected to each other. This is called a Type-B crossover fiber. Each of the two 4-channel NDR ports in the Twin-port transceiver has its own 4-channel optical connector that can linkto two single-port 400Gb/s NDR transceiver. Two fiber cables are needed for each Twin-port transceiver.Fiber cables are crossover cable Type-B that aligns the transmit laser with the opposite transceiver’s receiverphotodetector allowing to directly connect two transceivers together to maintain minimum optical losses, lowest backreflections, longest reach and increased reliability without the use of optical patch panels. For Twin-port transceivers,both cables must be the same type (straight or 1:2 splitter) although different lengths are allowed.
